UV and white light options: Available with UV light or a combination of UV and white light to ensure optimal illumination depending on the inspection environment.
Ideal for fluorescent penetrant testing. Frequently used in non-destructive testing.
UV video endoscope 365 nm – Precise inspection with ultraviolet light
The UV video endoscope with a wavelength of 365 nm is the ideal solution for demanding inspections where conventional cameras reach their limits. The use of UV light (365 nm) makes it possible to visualize materials, liquids, and surfaces that are not visible under normal light.
The UV video endoscope is a powerful tool for experts in materials testing, security inspection, and forensic analysis.
Perfect for precise inspections with UV fluorescence!
Technical Data |
Device (handset + display)Size: 360x160x60mm Display: 5.7 inch FHD, touch screen Resolution: 1980x1080 P Slots: Micro SD card (up to 512GB), HDMI, Type C Operation: >4h, battery, mains connection IP protection class: IP54 Operating temperature: -20°C~70°C Ambient temperature: -20°C~80°C |
System
|
Lens
|
ProbeLength: 1m – 3m Diameter: 3.9mm / 6.0mm Direction of movement: 360° articulation Lighting system: Fiber optics. *Reverse transmission of high-performance LED signals via fiber optic cables. Light/illumination: UV light / combination of UV and white light IP protection class: IP67 Operating temperature: -20°C~70°C Material: Flexible (tungsten wire mesh) |
Scope of delivery
|
